Eagle Spill Containment System

The Eagle system is used in Vented (flooded) and Valve Regulated Lead Acid (VRLA) battery applications with both Lead-Acid and Ni-Cad batteries. The Eagle is a patented, liner-based spill containment system that complies with all industry standards, as well as local, state, and federal regulations. It features a Class 1 fire-rated, corrosive-resistant, pre-formed, factory-made watertight liner. The metal barrier walls are made with an acid-resistant, safety yellow coating also available in ANSI grey. The Eagle system is UL 2436 compliant and includes UL Recognized dustless spill containment pillows that work with the overall Eagle System. Flame Retardant (FR) pillows that are also FM Approved are available.

FeaturesPatentsVideosInstaller Training

EAGLE™ SYSTEM

Features

Modular design configured to fit all standard rack styles and applications
Space-saving design maximizes aisle width
Corrosion-resistant liner with Class 1 fire rating (NFPA 101)
Standard safety yellow coating for anti-corrosive metal frames, also offered in ANSI grey
Anti-corrosive liner ensures reliable spill protection
Flame-retardant (FR) dustless pillows available with FM Approvals certification
Integrated brackets enable easy rack installation, eliminating the need for floor mounting

Certifications & Standards

UL 2436 compliant
UL Recognized Pillows (as part of a spill containment system)
UL NEBS (Seismic)
FM 4955
IEEE 1578
NFPA 855, Section 4
International Building Code (IBC)
International Fire Code (IFC) Section 608 (prior to 2018), Section 1206 (2018), Section 1207 (2021)
OSHA 1926.441

Specifications

4" Coated Steel Barriers with optional liners, including a standard 60 mil polymeric liner and an upgrade to an 80 mil liner
The system features 12"x12" UL Recognized Neutralization and Absorption Pillows (NABPILs) and 4"x24" Neutralization and Absorption Pillows (SOCs)
Pillows feature new and improved dustless Neutrasorb™ technology for facility cleanliness
Available options include Flame Retardant (FR) and UL Recognized Pillows (NABPILs)
Specifically designed KOH NABPILs and SOCs are available for Ni-Cad battery applications

6,308,728 - Oct. 30, 2001 - 09/428,192
6,395,417 - May 28, 2002 - 09/602,276
7,124,771 - Oct. 24, 2006 - 09/960,759
7,691,526 - Apr. 6, 2010 - 10/155,417

View Patents

Factory Installer Training

FIT EnviroGuard's UL Listed Spill Containment systems utilize a preformed liner, modular barriers and fire-resistant acid neutralization and absorption pillows. This course presents a proven process for installing the spill containment systems to ensure system is liquid-tight and installed per Underwriters Laboratories accepted procedure. Installation technicians will be able to confidently install EnviroGuard's spill containment systems for flooded, VRLA, battery cabinet and relay rack applications.

Learn more about this and our other available training courses
